Ardinox represent a global steel pipe producer for all major applications — oil&gas exploration andtransportation, power generation, mechanical and structural use, production is totally made in Europe. Seamless & welded up to DN 16"

ARDINOX represents ARFLU SA in Italy and Switzerland. ARFLU has 4 factories in Spain, Saudi Arabia, China and Indonesia. The key is the coordination of the different Departments that make up ARFLU. While the Engineering Department, improves and creates new models; The Quality Department obtains the certifications in addition to supervising the entire manufacturing process.

Production Gate, Globe, Swing & Y strainer Size: ½”-68" Pressure class: ASME 150-2500 Materials: WCB, LCB, WC6, C12A, CF8M, CN7M, UB6, Inconel625, Monel Etc Test and inspection: API598 Connection: Flanges, RTJ Flange, Butt Weld, Hub end, Groove Operation: Handwheel, wormgear, gearbox, pneumatic actuator, electric actuator

TRUNNION Ball valve produced in Italy Size: 2-48" Pressure Class: ASME 150-2500 Materials: WCB, WC6, C12A, CF8M, CN7M, Alloy 20, B148, UB6, Monel Etc Design & manufacture: API6D, ASME B16.34 Firesafe design: API607, API6FA Operation: Handlever, gearbox, pneumatic actuator, electric actuator

PNEUMATICA TOOLS Pepperl & Fuchs Festo Omron SMC And all the other most important brands

HERCULES- HEAVY DUTY ACTUATOR Torque: DA up to 200.000 Nm, SE 50.000 Nm Input Air pressure: 3-10 bar Materials: Ductile iron Norms: ISO5211, DIN3337, VDI/VDE-3845, NAMUR Operation temperature: ST -20°C up to 80° C HT -15° up to 150° - LT -40° up to 80°

ATLANTE - PNEUMATIC ACTUATOR Torque: DA up to 9744 Nm, SE 16 springs 4198 Nm Input Air pressure: 3-8 bar Materials: Aluminium, stainless steel Norms: ISO5211, DIN3337, VDI/VDE-3845, NAMUR Operation temperature: -20°C up to 80° C

Check valve Size: ½”-48" Pressure class: ASME 150-2500 Materials: GG25, GGG40, WCB, LCB, WC6, C12A, CF8M, CN7M, UB6, Inconel625, Monel Etc Connection: RF, RTJ flange, wafer e LUG

Knifegate valves Size: 2-48" Pressure class: PN16, ANSI150 Materials: GG25, GGG40, WCB, LCB, WC6, C12A, CF8, CN7M, UB6, Inconel625, Monel etc Test and inspection: API598 Operation: Handwheel, Wormgear, gearbox, pneumatic actuator, electric actuator

AURORA - Rubber seat butterfly valve Size: 2"-88" Pressure class: PN16, ANSI150 Materials: GG25, GGG40, WCB, LCB, LCC, CF8M, CF3, CF3M, B148, Etc Connection: Wafer, Lug and flanged type Operation : Handlever, gearbox, handwheel, pneumatic actuator, electric actuator

Double and triple eccentric valve Size: 2"-80" Pressure: 150LB, 300LB, 600LB, 900LB Materials: WCB, LCB, LCC, WC5, WC6, WC9, CF8, CF8M, CF3, CF3M, B148 etc. Connection: Wafer type, Lug Type, Flanged, BW Operation: Handwheel, gearbox, pneumatic actuator, electric actuator
